Moving head LEDseries
(WKY-BEAM36) LED MOVING BEAM
    • Demo
    Technical parameter

    Voltage: AC 90-240v, 50/60Hz

    Power consumption: 150w

    Lamp: CREE XPE 3w × 36PCS LED(R8,G10,B10,W8)

    Channel: 11 CH / 15 CH

    Control: DMX, master slave mode, auto mode, sound mode

    Movement range: Pan: 450°/ Tilt: 270°

    Carton Size: 267×254×304mm

    Beam Angle:2°  G.W.: 6.5kg

    Display: Color display(Chinese / English menu)

    Channel model

    Channel

    Channel mode

    11 Channel

    15 Channel

    1

    General dimmer

    General dimmer

    2

    Red dimmer

    Red dimmer

    3

    Green dimmer

    Green dimmer

    4

    Blue dimmer

    Blue dimmer

    5

    White dimmer

    White dimmer

    6

    user defined color dimmer

    user defined color dimmer

    7

    X

    X

    8

    Y

    Y

    9

    X fine（16Bit）

    X fine（16Bit）

    10

    Y fine（16Bit）

    Y fine（16Bit）

    11

    XY speed

    XY speed

    12

    Strobe

    13

    Auto, sound

    14

    Optional macro

    15

    ID code settings

    【Back】
    Previous record：WKY-BEAM4A 4X25W LED MOVING BEAM　
    Next record：WKY-BEAM36B 36*3w led moving beam
